Hikvision iDS-7108HQHI-M1/S AcuSense DVR

Hikvision iDS-7108HQHI-M1/S AcuSense DVR
Hikvision iDS-7108HQHI-M1/S AcuSense DVR delivers intelligent high-definition surveillance with deep learning detection and efficient compression. This compact mini 1U recorder suits medium installations requiring accurate alerts, reduced false alarms, and easy remote access.

Hikvision iDS-7108HQHI-M1/S AcuSense DVR Use Cases
The Hikvision iDS-7108HQHI-M1/S AcuSense DVR fits medium-scale environments. Homeowners monitor larger properties and outbuildings. Retail stores cover sales floors, entrances, and stock areas. Offices secure workspaces, receptions, and parking lots. Small warehouses watch loading bays and inventory zones.
Eight analog channels offer balanced coverage. Users protect multiple zones without excess capacity. Businesses achieve smart security economically.
Hybrid design supports system evolution. Installers combine existing analog cameras with IP ones. This approach minimizes upgrade expenses.
AcuSense features prioritize real events. Users receive alerts for humans and vehicles only.

Hikvision iDS-7108HQHI-M1/S AcuSense DVR Compatibility
The Hikvision iDS-7108HQHI-M1/S AcuSense DVR processes various signals. It handles HDTVI, AHD, HDCVI, CVBS analog cameras, and IP cameras up to 6 MP.
Default adds two IP channels. Enhanced mode expands to twelve channels.
All eight analog channels support audio over coaxial cables. Compatible cameras provide sound without separate lines.
Remote monitoring uses the Hik-Connect app. Users view live streams and recordings on mobile devices.
USB Wi-Fi dongle enables wireless connections. This suits sites lacking Ethernet cabling.

Hikvision iDS-7108HQHI-M1/S AcuSense DVR Key Advantages
Motion Detection 2.0 employs deep learning. It classifies humans and vehicles reliably. False alarms from objects like leaves or lights drop dramatically.
Perimeter protection monitors up to four channels. It detects intrusions and line crossings accurately.
H.265 Pro+ compression optimizes storage usage. Users store more footage on limited drives. Long-term costs reduce substantially.
The mini 1U chassis installs in small spaces. HDMI and VGA outputs work simultaneously for flexible displays.
Smart search filters by object type. Investigators locate events quickly and efficiently.

Technical Specifications
Video and Audio

Analog Video Input: 8-ch BNC (1.0 Vp-p, 75 Ω), supports coaxitron
HDTVI Input: Up to 4 MP@30 fps, 1080p@30 fps, 720p@30 fps
AHD/HDCVI Input: Up to 4 MP@30 fps, 1080p@30 fps, 720p@30 fps
CVBS Input: Supported
IP Video Input: 2-ch default (up to 12-ch enhanced), up to 6 MP
Video Compression: H.265 Pro+/H.265 Pro/H.265/H.264+/H.264
Encoding Resolution: Up to 4 MP lite/3 MP/1080p lite
Audio Input: 1-ch RCA + 8-ch via coaxial cable
Audio Output: 1-ch RCA
Two-Way Audio: Supported via RCA

Recording and Playback

Recording Frame Rate: Up to 15 fps at 1080p
Synchronous Playback: 8-ch
Smart Search: By human/vehicle events

Smart Functions

Motion Detection 2.0: All analog channels (human/vehicle)
Perimeter Protection: Up to 4-ch (human/vehicle)

Network

Network Interface: 1 × RJ45 10/100 Mbps
Total Bandwidth: 96 Mbps
Remote Connections: Up to 64 users
Protocols: TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, HTTPS, ONVIF

Storage

SATA Interface: 1 × SATA
Capacity: Up to 10 TB per disk

Interface

Video Output: 1-ch HDMI + 1-ch VGA (simultaneous)
USB Interface: 2 × USB 2.0

General

Power Supply: 12 VDC
Consumption: ≤ 12 W (without HDD)
Working Temperature: -10 °C to +55 °C
Dimensions (W × D × H): 200 × 200 × 45 mm
Weight: ≤ 1 kg (without HDD)
