Hikvision DS-7116HGHI-M1/T 16-Channel DVR

Hikvision DS-7116HGHI-M1/T 16-Channel DVR offers extensive high-definition surveillance with intelligent detection and advanced compression. This powerful recorder suits larger installations requiring comprehensive coverage, accurate alerts, and efficient remote access.

Hikvision DS-7116HGHI-M1/T DVR Use Cases

The Hikvision DS-7116HGHI-M1/T 16-Channel DVR shines in demanding environments. Large homes use it for full perimeter and interior monitoring. Shopping malls deploy it across multiple entrances and floors. Schools apply it to hallways, playgrounds, and parking areas. Factories install it for production lines and storage zones.

This unit manages sixteen analog channels seamlessly. Operators cover extensive areas without blind spots. Commercial sites gain thorough protection with one device.

Hybrid functionality permits mixed deployments. Users integrate legacy analog cameras with modern IP ones. This flexibility supports phased system expansions cost-effectively.

Hikvision DS-7116HGHI-M1/T DVR Compatibility

The Hikvision DS-7116HGHI-M1/T 16-Channel DVR handles diverse formats. It accepts HDTVI, AHD, HDCVI, CVBS analog cameras, and IP cameras. Default supports two IP channels, expandable to eighteen.

All sixteen analog channels enable two-way audio with suitable HDTVI cameras. Operators speak directly through coaxial connections.

Remote monitoring integrates with the Hik-Connect app. Viewers access live and recorded footage on mobile devices effortlessly.

Hikvision DS-7116HGHI-M1/T DVR Key Advantages

Motion Detection 2.0 leverages deep learning technology. It classifies humans and vehicles precisely. Unwanted notifications from environmental factors drop dramatically.

H.265 Pro+ compression optimizes storage usage. Users retain weeks of footage on single drives. Operational costs decrease over time.

The mini 1U form factor fits constrained spaces. Simultaneous HDMI and VGA outputs accommodate different display types.

Technical Specifications

Video and Audio

• Analog Video Input: 16-ch BNC (1.0 Vp-p, 75 Ω), supports coaxitron
• HDTVI Input: 1080p@25/30 fps, 720p@25/30 fps
• AHD Input: 1080p@25/30 fps, 720p@25/30 fps
• HDCVI Input: 1080p@25/30 fps, 720p@25/30 fps
• CVBS Input: Supported
• IP Video Input: 2-ch (up to 18-ch), up to 5 MP resolution
• Video Compression: H.265 Pro+/H.265 Pro/H.265/H.264+/H.264
• Encoding Resolution: 1080p Lite@15 fps
• Audio Input: 1-ch RCA + 16-ch via coaxial cable
• Audio Output: 1-ch RCA
• Two-Way Audio: Supported via coaxial (reuses audio input)

Recording and Playback

• Recording Frame Rate: Up to 15 fps for 1080p Lite
• Synchronous Playback: 16-ch
• Smart Search: By human/vehicle events

Network

• Network Interface: 1 × RJ45 10/100 Mbps
• Total Bandwidth: 96 Mbps
• Remote Connections: Up to 128 users
• Protocols: TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, HTTPS

Storage

• SATA Interface: 1 × SATA
• Capacity: Up to 10 TB per disk

Interface

• Video Output: 1-ch HDMI + 1-ch VGA (simultaneous)
• USB Interface: 2 × USB 2.0

General

• Power Supply: 12 VDC
• Consumption: ≤ 7 W (without HDD)
• Working Temperature: -10 °C to +55 °C
• Dimensions (W × D × H): 285 × 210 × 45 mm
• Weight: ≤ 1.8 kg (without HDD)

Trust and Support

Threeways Gadget Hub provides genuine Hikvision items from authorized sources. Each product carries the standard manufacturer warranty. Our Nairobi team offers expert installation advice, configuration support, and ongoing assistance. Nationwide delivery ensures quick access. Check our main website for full service details.
