Hikvision DS-3E0505-O Gigabit Switch

Hikvision DS-3E0505-O Gigabit Switch provides fast and reliable Ethernet connectivity for small-scale networks and surveillance setups.

This compact 5-port unmanaged Gigabit switch ensures high-speed data transfer without configuration. Small offices, retail shops, homes, and entry-level security systems in Kenya choose it for simple, high-performance networking. It connects IP cameras, computers, NVRs, and other devices effortlessly. The switch supports full Gigabit speeds on all ports. Users experience smooth video streaming. The plastic housing keeps it lightweight. Many Kenyan installers select this model for budget-friendly, plug-and-play Gigabit solutions.

Why Hikvision DS-3E0505-O Gigabit Switch Performs Efficiently

Basic Gigabit networks need uncomplicated, energy-efficient switches. This model offers 5 Gigabit Ethernet ports. It supports auto-negotiation for 10/100/1000 Mbps speeds. IEEE 802.3, 802.3u, and 802.3ab standards guarantee compatibility. Flow control prevents packet loss during heavy traffic. The fanless design runs completely silent. Low power consumption reduces electricity costs. The durable plastic case suits desktop or wall mounting. Compact size fits limited spaces. Wide operating temperature range matches Kenyan conditions.

Hikvision DS-3E0505-O Gigabit Switch suits everyday applications. Small retail stores connect POS terminals and cameras. Homes link security recorders and smart TVs. Offices share internet and files among a few devices. The switch handles 4K video streams reliably. LED indicators display link and activity status. Simple setup requires no software.

Detailed Use Cases and Compatibility

Hikvision DS-3E0505-O Gigabit Switch works well in entry-level surveillance. Connect up to 5 Gigabit devices directly. Use it as an extension switch in larger networks. Pair it with non-PoE NVRs or recorders. The switch supports standard Ethernet equipment. It integrates with Hikvision cameras and third-party devices. Auto MDI/MDIX eliminates the need for crossover cables. Combine with high-quality displays from our monitor collection. View connected feeds clearly. Set up basic control stations using our desktop computers.

Print security logs or reports quickly. Choose printers from our printer collection. Teams check connection status instantly. Green and amber LEDs indicate speed and activity. Troubleshooting remains straightforward. The switch supports jumbo frames for improved throughput.

Technical Specifications

• Ports: 5 × 10/100/1000 Mbps RJ45 Gigabit Ethernet
• Standards: IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x
• Switching Capacity: 10 Gbps
• Packet Forwarding Rate: 7.44 Mpps
• MAC Address Table: 2 K
• Packet Buffer: 1 Mbit
• Transmission Distance: Up to 100 m (Cat5e/Cat6 cable)
• Power Supply: 5 VDC / 0.6 A (external adapter included)
• Power Consumption: ≤ 3.5 W
• Surge Protection: 2 kV (common mode)
• Dimensions: 98 × 78 × 25 mm
• Operating Temperature: 0 °C to 40 °C
• Operating Humidity: 5% to 95% (non-condensing)
• Housing: Plastic, fanless design
• Installation: Desktop or wall-mounted
• Indicators: Power, Link/Act LEDs per port
• Weight: ≈ 0.18 kg

These specifications ensure fast and reliable Gigabit performance. Features support easy integration.

Warranty and Support You Can Trust

Threeways Gadget Hub supplies genuine Hikvision products. Hikvision DS-3E0505-O Gigabit Switch includes manufacturer warranty coverage. Local support in Kenya responds quickly. Setup guidance and basic troubleshooting come included. Extended service options provide added peace of mind. Our expert team assists every step. Customers receive dependable service. Reliability builds confidence.

Learn more from trusted sources:

• Hikvision Official Networking Overview
• IEEE Ethernet Standards
• Gigabit Ethernet Technology Guide

Upgrade to Gigabit networking today. Order Hikvision DS-3E0505-O Gigabit Switch for fast delivery across Kenya.
