Hikvision DS40HKVS-VX1 4TB Surveillance HDD

Hikvision DS40HKVS-VX1 4TB Surveillance Hard Disk offers high-capacity, purpose-built storage for professional 24/7 video surveillance. This 3.5-inch SATA drive is engineered specifically for DVRs and NVRs. It supports demanding multi-camera recording environments. Security professionals select it for excellent reliability and consistent performance.

This drive manages intensive write workloads without compromise. It features advanced firmware optimizations to minimize frame loss. The large cache buffer ensures smooth multi-stream handling. It suits medium to large installations in homes, offices, retail stores, and small enterprises. The HDD provides extended recording duration at high resolutions. It reduces system vibration and maintains data integrity. Users benefit from quiet operation and long-term stability.

Detailed Use Cases and Compatibility

Hikvision DS40HKVS-VX1 4TB Surveillance Hard Disk excels in various surveillance deployments. Use it in 8-channel to 32-channel DVRs for comprehensive home or business monitoring. It stores weeks or months of footage from multiple HD or 4K cameras. Install it in Hikvision NVRs to support IP camera arrays efficiently.

The drive handles continuous recording from 16 to 32 channels at 1080p or higher. It works seamlessly with Hikvision, HiLook, and compatible third-party recorders. The 4 TB capacity accommodates extended retention periods without overwriting critical events quickly. It integrates into NAS systems dedicated to video storage. The 180 TB/year workload rating supports always-on operation. It performs reliably across a wide temperature range from 0°C to 60°C. This makes it suitable for Kenyan climates and enclosed equipment racks.

For complete surveillance solutions, visit Threeways Gadget Hub. Browse our desktop computers to create powerful recording and management workstations.

Technical Specifications

General

• Model: DS40HKVS-VX1
• Capacity: 4 TB
• Form Factor: 3.5-inch
• Interface: SATA 6.0 Gb/s
• Rotation Speed: 5400 RPM
• Cache Buffer: 256 MB
• Workload Rating: 180 TB/year
• Cameras Supported: Up to 32 HD streams

Performance

• Maximum Sustained Transfer Rate: Up to 180 MB/s
• Average Latency: ~5.6 ms
• Shock Resistance: 350 G (2 ms) operating
• Load/Unload Cycles: 600,000
• MTBF: 1,000,000 hours

Power & Environmental

• Power Consumption: Operating ~5.0 W, Idle ~3.0 W, Standby ~0.4 W
• Operating Temperature: 0°C to 60°C
• Non-Operating Temperature: -40°C to 70°C
• Relative Humidity: 5% to 90% (non-condensing)
• Acoustics: Idle ~20–23 dB

Additional Features

• Optimized for 24/7 continuous surveillance recording
• Advanced Format 512e technology
• Built-in rotational vibration sensors
• Firmware tuned for video streaming and low frame loss

Discover more storage choices in our storage collection.

Trust-Building with Warranty and Support

Threeways Gadget Hub supplies authentic Hikvision surveillance hard drives. The DS40HKVS-VX1 comes with full manufacturer quality certification. It complies with international standards for continuous-use reliability. Our Nairobi team offers expert compatibility verification and installation recommendations. We provide fast delivery throughout Kenya. Contact us for dedicated technical assistance. Choose this 4 TB drive for secure, high-capacity video storage you can trust.
