Hikvision DS-K4H258D Double Door Magnetic Lock

Hikvision DS-K4H258D Double Door Magnetic Lock secures double doors with 280 kg thrust per side. This reliable electromagnetic lock ensures strong holding force. It fits access control systems seamlessly. The lock suits various door types in Kenya. It provides LED status indication. Anti-residual design prevents sticking. Users enjoy fail-safe operation.

Use Cases and Compatibility

Hikvision DS-K4H258D Double Door Magnetic Lock works in offices, hotels, hospitals, schools, malls, and warehouses. It secures main entrances and internal double doors. Install on wooden, glass, metal, or fireproof doors. The 90° opening angle supports standard swings. It handles high-traffic areas daily.

This lock integrates with Hikvision controllers and readers. Pair with card readers or keypads for entry. It connects to exit buttons for egress. The fail-safe design unlocks on power loss. This aids emergency evacuation. Use with 12 VDC or 24 VDC supplies. Default stays at 12 VDC.

The device operates from -10°C to 55°C. This range matches Kenya’s climates. Coastal humidity and inland heat cause no issues. Humidity up to 95% remains safe. Surface mount on frames. Optional brackets aid glass doors.

It supports door status monitoring. LED shows locked or unlocked. This enhances security management.

Explore access control integrations in our desktop computers category.

Technical Specifications

Hikvision DS-K4H258D Double Door Magnetic Lock follows quality standards. Key specifications include:

• Holding Force — 280 kg (617 lbs) × 2
• Power Supply — 12 VDC (default), 340 mA × 2; or 24 VDC
• Unlock Method — Current interruption
• Suitable Doors — Wooden, glass, metal, fireproof; 90° opening angle
• Working Temperature — -10°C to 55°C (14°F to 131°F)
• Working Humidity — 0% to 95% (relative)
• Dimensions (Lock Body) — 500 mm × 45 mm × 25 mm (19.7″ × 1.8″ × 1.0″)
• Dimensions (Armature Plate) — 182 mm × 38 mm × 12.5 mm (7.2″ × 1.5″ × 0.5″) × 2
• Weight — 4.2 kg (9.3 lbs)
• Material — Hard anodizing electroplating; abrasion-proof
• Indicator — Green LED for working status
• Additional Features — Anti-residual magnetism; internal MOV; no mechanical damage

The electromagnetic force ensures reliability. It prevents forced entry.

Learn magnetic lock standards from the Door and Hardware Institute. It explains holding force ratings.

Benefits of Choosing This Magnetic Lock

This lock offers strong double-door security. Fail-safe unlocks aid safety. LED provides clear status. Versatile power options ease installation. Durable materials reduce wear. Anti-residual feature ensures smooth release. Wide environmental tolerance fits Kenya. It integrates easily with systems. Low maintenance saves costs. Overall, it delivers robust protection.

Trust-Building: Warranty and Support

Threeways Gadget Hub provides genuine Hikvision DS-K4H258D Double Door Magnetic Lock units. We offer full manufacturer warranty. Hikvision supports this lock reliably. Customers get installation and wiring advice.

Our Nairobi team answers quickly. We deliver fast across Kenya. Trust our service for satisfaction. The solid build promises years of use. Many setups last over 5 years.

Browse more locks in our monitors category.

Check British Standards Institution for door hardware guidelines.

Shop confidently at Threeways Gadget Hub. We focus on quality and care.
