Hikvision DS-K4G100 Electric Strike Lock provides robust, electromagnetic security for controlled access doors. This versatile electric strike features selectable fail-secure and fail-safe modes. It delivers strong holding force against forced entry. The device suits various door materials in Kenya. It ensures reliable operation with durable construction. Users benefit from easy integration and long-term performance.

Use Cases and Compatibility

Hikvision DS-K4G100 Electric Strike Lock installs on wooden, metal, and PVC doors. It secures offices, hotels, hospitals, schools, retail stores, and residential entrances. Use it in access control systems for single or double doors. The strike releases the latch electrically. This allows free egress when unlocked. It pairs with Hikvision controllers, readers, or exit buttons. Connect via dry contact for status monitoring. Fail-safe mode unlocks on power loss for safety. Fail-secure mode keeps doors locked during outages for protection.

The lock handles high-traffic areas effectively. Depth of latch groove measures 15 mm. This accommodates standard latches. Strong suction prevents forced opening. Double insulation enhances electrical safety. It operates from -10°C to 55°C. This range fits Kenya’s climate variations. Humidity up to 95% causes no issues. Surface mounting simplifies installation. It supports 90° door openings.

Discover related access control products in our desktop computers category.

Technical Specifications

Hikvision DS-K4G100 Electric Strike Lock meets high performance standards. Key specifications include:

• Maximum Thrust — 800 kg (1764 lb) static linear
• Input Voltage — 12 VDC, 320 mA or 24 VDC, 160 mA ±15%
• Fail Modes — Selectable fail-secure or fail-safe
• Latch Material — US304 stainless steel
• Plate Material — Wire-drawing surface
• Latch Groove Depth — 15 mm
• Signal Output — Dry contact (NO when locked, NC when unlocked)
• Electromagnetic Coil Life — 100,000 cycles (powered on)
• Working Temperature — -10°C to 55°C (14°F to 131°F)
• Working Humidity — 0% to 95% (non-condensing)
• Dimensions — 165 mm × 43.7 mm × 35 mm (6.5″ × 1.7″ × 1.4″)
• Weight — 0.4 kg (0.9 lb)
• Additional Features — Strong suction, double insulation

The electromagnetic design ensures quick response. It protects doors from unauthorized access.

Learn about electric strike standards from the Door and Hardware Institute. It explains thrust ratings and fail modes.

Benefits of Choosing This Electric Strike Lock

This lock offers exceptional holding strength. Selectable modes provide installation flexibility. Stainless steel construction resists corrosion. The 100,000-cycle rating ensures durability. Compact size fits various frames. Dry contact output aids monitoring. Wide voltage compatibility simplifies wiring. Strong suction enhances security. It reduces maintenance needs. Overall, it delivers reliable, cost-effective protection.

Trust-Building: Warranty and Support

Threeways Gadget Hub supplies genuine Hikvision DS-K4G100 Electric Strike Lock units. We include full manufacturer warranty. Hikvision provides dependable support for this hardware. Customers receive expert guidance on configuration and installation.

Our Nairobi team responds promptly to inquiries. We offer fast delivery across Kenya. Trust our service for lasting satisfaction. The robust design promises years of reliable operation. Many installations exceed 5 years with minimal issues.

Explore more security accessories in our monitors category.

Refer to British Standards Institution for door hardware best practices.

Shop confidently at Threeways Gadget Hub. We prioritize quality and customer care.
