Hikvision DS-3WF0BC-2NT(B)(O-STD) Elevator Wireless Bridge

Hikvision DS-3WF0BC-2NT(B)(O-STD) 2.4GHz 300Mbps 200m Elevator Wireless Bridge
Hikvision DS-3WF0BC-2NT(B)(O-STD) 2.4GHz 300Mbps 200m Elevator Wireless Bridge provides a reliable wireless link for elevator CCTV systems. This pair of bridges transmits video data without cables. It suits high-rise buildings in Nairobi and Kenya. Property managers avoid complex wiring. Installers save time and costs. The bridge ensures stable video feeds from moving elevators.
The device operates on 2.4 GHz frequency. It achieves up to 300 Mbps throughput. Plug-and-play design simplifies setup. Built-in antennas focus the signal. Real-time status indicators aid alignment. It supports point-to-point connections effectively.

Use Cases and Compatibility
This wireless bridge excels in elevator surveillance applications. In residential towers, transmit camera feeds from elevator cars to the shaft. Commercial buildings maintain clear video during movement. Hotels secure lifts with continuous monitoring. Industrial sites use it for vertical transport oversight.
The pair includes one AP and one CPE unit. Connect IP cameras in the elevator to the CPE. Link the AP to the network in the shaft. Transmit up to 200 m distance reliably. Use 10/100 Mbps RJ45 ports for camera and network connections.
Support IEEE 802.11b/g/n standards with 2×2 MIMO. Pair with Hikvision IP cameras and NVRs. Integrate into existing PoE setups. Power via 12 VDC adapter or passive PoE. Operate in environments with metal interference. Align using signal LEDs for optimal performance.
For dependable wireless solutions in Kenya, visit Threeways Gadget Hub. Check monitors for viewing stations.

Technical Specifications
Wireless Parameters

Frequency Band: 2.4 GHz (2400 MHz to 2483.5 MHz)
Wireless Standard: IEEE 802.11b/g/n (2×2 MIMO)
Max. Air Interface Rate: ≤ 300 Mbps
Antenna: Built-in 7 dBi 2×2 MIMO
Antenna Beamwidth: Horizontal 50° to 65°, Vertical 50° to 65° (model dependent)
Transmission Distance: Up to 200 m

Interfaces

Ethernet Ports: 2 × 10/100 Mbps RJ45 (one for data, one for PoE/power)
Power Supply: 12 VDC / 1 A or passive PoE (24 V)

General

Dimensions (per unit): Approx. 90.8 mm × 187.87 mm × 57.87 mm (or 80 mm × 41.94 mm × 136 mm variant)
Net Weight (per unit): Approx. 0.26 kg
Power Consumption: Max. approx. 2 W to 5 W
Working Temperature: -30°C to 60°C (-22°F to 140°F) typical for outdoor/elevator use
Working Humidity: 5% to 95% (non-condensing)
Installation: Pole or wall mounting with straps
Features: Plug-and-play pairing, signal strength LEDs, topology management in some modes

The bridge includes weather-resistant housing. It handles elevator vibrations. LEDs show power, LAN, and signal quality. Easy alignment ensures strong links.
Explore desktop computers at Threeways Gadget Hub for NVR connections.

Reliable Performance and Support
Threeways Gadget Hub supplies genuine Hikvision wireless bridges to Kenyan clients. The Hikvision DS-3WF0BC-2NT(B)(O-STD) 2.4GHz 300Mbps 200m Elevator Wireless Bridge includes a manufacturer warranty against defects. Our Nairobi team offers expert support. Get help with installation, alignment, pairing, and troubleshooting. Access firmware updates when available. Depend on our expertise for seamless elevator CCTV deployments.
Refer to Hikvision’s wireless bridge products here, transmission solutions here, and networking guidelines here.
